Alva Machinery
Alva Machinery Double Shaft Metal Scrap Shredder is a heavy-duty primary crushing equipment specially designed for ferrous and non-ferrous metal waste recycling. It adopts dual independent drive systems and high-strength alloy steel blades, which can efficiently shred various metal materials through the combined action of shearing, tearing and extrusion. Our metal shredders are widely used in scrap metal recycling plants, automobile dismantling yards, steel mills and non-ferrous metal processing industries, with processing capacity ranging from 500kg/h to 50t/h.
Our double shaft metal scrap shredder can process various ferrous and non-ferrous metal wastes:
Note: Customized configurations are available according to your specific material and output requirements.
Model | Feed Opening Size (mm) | Motor Power (kW) | Blade Quantity | Processing Capacity (t/h) | Overall Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
ALVA-DSSM-600 | 600×400 | 2×11 | 20 | 0.5-2 | 2200×1500×1800 | 3500 |
ALVA-DSSM-800 | 800×500 | 2×15 | 24 | 1-3 | 2600×1800×2000 | 5200 |
ALVA-DSSM-1000 | 1000×600 | 2×22 | 30 | 3-8 | 3200×2200×2300 | 8500 |
ALVA-DSSM-1200 | 1200×700 | 2×37 | 36 | 8-15 | 3800×2600×2600 | 13500 |
ALVA-DSSM-1500 | 1500×800 | 2×55 | 48 | 15-25 | 4500×3200×3000 | 22000 |
ALVA-DSSM-2000 | 2000×1000 | 2×90 | 64 | 25-50 | 5800×4000×3800 | 38000 |
Ultra-high Torque Output
Dual motor + dual planetary gearbox independent drive system, providing 30% higher torque than traditional single drive shredders
Equipped with automatic overload reversal protection, effectively preventing jamming when processing large and hard metal materials
Durable Blade System
Standard configuration of SKD-11/D2 alloy steel blades, heat treated to HRC 58-62, with excellent wear resistance and impact resistance
Detachable assembled blade structure, single blade can be turned over for use, greatly reducing maintenance costs
Customizable Hardox 450/500 blades for processing thick steel plates and heavy metal castings
Heavy Duty Structural Design
Integral welded heavy duty frame, reinforced rib structure, ensuring stable operation under long-term high load conditions
Thickened steel plate housing, anti-vibration and noise reduction design, meeting international safety standards
Intelligent Control System
PLC automatic control system with touch screen operation interface
Real-time monitoring of equipment operating status, fault alarm and remote diagnosis function
Adjustable shredding speed according to different material characteristics
✅ 20+ years of experience in manufacturing solid waste recycling equipment
✅ CE and ISO certified products, exported to more than 80 countries
✅ Professional technical team provides customized solutions
✅ 12-month warranty period and lifelong after-sales service
✅ Fast delivery time: 15-30 days for standard models
✅ Overseas installation and commissioning service available
Contact us today to get the latest price and detailed technical information about our products. Our professional engineers will provide you with the most suitable recycling solution according to your needs.
