Eddy current sorter is a kind of equipment that realizes material classification and separation by using eddy current effect. It induces eddy current in the conductor material through alternating magnetic field, and realizes the separation of materials with different conductive properties by using the interaction between the reverse electromagnetic field generated by eddy current and the primary magnetic field. The equipment is widely used in waste recycling, metal recycling and other fields. The working principle of the eddy current sorter is based on the eddy current effect. The eddy current sorter uses an electromagnet to generate an alternating magnetic field, the frequency and strength of which can be adjusted according to different application requirements. The sensor is mounted on the workbench and is used to detect the eddy current generated by the material. The sensor sends the detected signal to the control system for processing. The control system classifies and separates the materials according to the signals from the sensors. According to the strength and characteristics of the eddy current, the control system can determine the types of different materials and separate them through the appropriate device. The separated material is collected into the appropriate container for subsequent processing and utilization.
| Quantity: | |
|---|---|
The ALVA Eddy Current Separator adopts the principle of electromagnetic induction to achieve efficient separation of non-magnetic non-ferrous metals from mixed materials. It is mainly applied in industrial scenarios such as solid waste treatment and non-ferrous metal recycling. The equipment can accommodate the treatment of various types of mixed materials, has a stable mechanical structure and automatic operation capability, can achieve seamless connection with existing production lines, meet the needs of continuous industrial operations, and facilitate resource recycling and environmentally friendly production.
| Model | Feed Belt | Energy Consumption | Load Bearing | External Dimensions | |||||
| Feed Width (mm) | Feed Length | Feed Size | Capacity (r/b) | Motor Power (w) | Weight (kg) | L (Length, m) | W (Width, m) | H (Height, m) | |
| TLFX(A)-5 | 300 | 1500mm | >1m r | 6 | 5.9 | 730 | 4600 | 1.123 | 1.2 |
| TLFX(A)-6 | 400 | 1500mm | >1m r | 10 | 5.9 | 895 | 4600 | 1.223 | 1.2 |
| TLFX(A)-6.5 | 400 | 1500mm | >1m r | 15 | 5.9 | 950 | 4600 | 1.423 | 1.2 |
| TLFX(A)-8 | 600 | 1500mm | >1m r | 20 | 5.9 | 1225 | 4600 | 1.623 | 1.2 |
| TLFX(A)-10 | 800 | 1500mm | >1m r | 25 | 6.3 | 1555 | 4600 | 1.823 | 1.2 |
| TLFX(A)-12 | 1000 | 1500mm | >1m r | 30 | 7 | 1875 | 4600 | 2.023 | 1.2 |
| TLFX(A)-14 | 1200 | 1500mm | >1m r | 35 | 8.8 | 2275 | 4600 | 2.223 | 1.2 |
| TLFX(A)-16 | 1400 | 1500mm | >1m r | 40 | 10 | 2850 | 4600 | 2.423 | 1.2 |
| TLFX(A)-17 | 1500 | 1500mm | >1m r | 45 | 10 | 3150 | 4600 | 2.523 | 1.2 |
| TLFX(A)-20 | 1800 | 1500mm | >1m r | 50 | 10.7 | 3650 | 5000 | 2.823 | 1.2 |
| TLFX(A)-22 | 2000 | 1500mm | >1m r | 55 | 13 | 4500 | 5000 | 3.023 | 1.2 |
3. Core Advantages
1.Non-contact Dry Separation SystemRealizes material separation based on the electromagnetic induction principle, adapts to the entire process of solid waste treatment, and complies with circular economy and environmental protection policies.
2.Intelligently Adjustable Magnetic System StructureThe magnetic roller adopts an eccentric layout and magnetic system protection mechanism. Magnetic field parameters can be precisely adjusted to adapt to non-magnetic non-ferrous metals of different particle sizes and shapes, achieving differentiated separation paths for materials such as copper and aluminum.
3.Full-process Automated Integrated ControlEquipped with a PLC programmable control system and an intelligent touch operation interface, it supports variable frequency speed regulation and baffle gap adjustment. It can be seamlessly connected to existing production lines to realize continuous operation and unattended operation.
4.High-strength Stable Mechanical StructureCore components are made of industrial-grade materials, and the magnetic source adopts permanent NdFeB magnet material. The main shaft is equipped with a thermal protection function. The overall structure is compact and runs stably, adapting to high-intensity operation scenarios of industrial production lines.
5.Multi-scenario Material CompatibilityCapable of processing various mixed materials such as electronic waste, automotive dismantling waste, waste cables and industrial waste, it covers the entire industrial chain of non-ferrous metal recycling and supports customized separation needs under different working conditions.
4.Product Uses
It is mainly used for sorting non-ferrous metals such as copper and aluminum in industrial waste and domestic waste. Domestic waste incineration slag, domestic waste, paper tailings, waste glass recycling, wood chips, scrap metal recycling, electronic waste recycling, waste plastic recycling.
5.Product Operate Guide
First check the components and circuits of the equipment, evenly feed after starting, observe the operation during operation, stop after the job, and finally check and maintain.
