Heavy Duty PVC & Plastic Steel Crusher for Pipe, Profile & Window Recycling
| Availability: | |
|---|---|
| Quantity: | |
Alva Machinery
Our double shaft metal scrap shredder can process various ferrous and non-ferrous metal wastes:
Note: Customized configurations are available according to your specific material and output requirements.
Model | Feed Opening Size (mm) | Motor Power (kW) | Blade Quantity | Processing Capacity (t/h) | Overall Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
ALVA-PC-400 | 400×300 | 15 | 12 | 0.3-1 | 1800×1200×1600 | 2200 |
ALVA-PC-600 | 600×400 | 30 | 18 | 1-2.5 | 2200×1600×2000 | 4500 |
ALVA-PC-800 | 800×500 | 45 | 24 | 2.5-5 | 2600×2000×2400 | 7800 |
ALVA-PC-1000 | 1000×600 | 75 | 30 | 5-8 | 3000×2400×2800 | 12000 |
Anti-Corrosion & Sealed Design
All contact parts are made of corrosion-resistant materials, and bearings adopt double-sealed structure
Effectively prevents hydrogen chloride gas generated during PVC crushing from corroding the equipment
Fully enclosed crushing chamber with negative pressure dust removal interface, meeting international environmental protection standards
Water Cooling System & Low Speed Design
Built-in circulating water cooling system controls the temperature of the crushing chamber below 60°C
Optimized rotor speed (600-800rpm) avoids high-temperature thermal decomposition of PVC
Eliminates the risk of toxic gas generation and material discoloration
High Hardness & Wear-Resistant Blades
Standard configuration of Cr12MoV alloy steel blades with anti-corrosion surface treatment
Blades can be turned over for use, effectively extending service life by 2 times
Adjustable blade gap (0.1-0.3mm) ensures uniform particle size of finished products
Intelligent & Easy Maintenance
Siemens PLC automatic control system with overload protection and automatic reverse function
Openable body design with quick-release bolts, convenient for internal inspection and blade replacement
Screen mesh aperture is adjustable (3-15mm), can control the finished product size according to demand
✅ 20+ years of experience in manufacturing solid waste recycling equipment
✅ CE and ISO certified products, exported to more than 80 countries
✅ Professional technical team provides customized solutions
✅ 12-month warranty period and lifelong after-sales service
✅ Fast delivery time: 15-30 days for standard models
✅ Overseas installation and commissioning service available
Contact us today to get the latest price and detailed technical information about our products. Our professional engineers will provide you with the most suitable recycling solution according to your needs.
