Alva Machinery Plastic Pulverizer is a professional high-speed grinding equipment designed for universal plastic recycling applications. It adopts an optimized turbo-disc hybrid structure combined with air-water dual cooling system, which can efficiently grind most common rigid plastic particles into uniform fine powder without thermal degradation. Our plastic pulverizers are widely used in plastic recycling plants, injection molding factories and plastic profile manufacturers, with processing capacity ranging from 100kg/h to 800kg/h.
Note: Customized configurations are available according to your specific material and output requirements.
Model | Type 400 | Type 600 | Type 800 | Type 1000 |
|---|---|---|---|---|
Grinding disc diameter | 400 mm | 600 mm | 800 mm | 1000 mm |
Number of grinding blades | 18 pcs | 28 pcs | 36 pcs | 42 pcs |
Main motor power | 18–30 kW | 45–55 kW | 75–90 kW | 90–110 kW |
Spindle speed | 3900 r/min | 3600 r/min | 2800 r/min | 2600 r/min |
Suction fan power | 2.2–3 kW | 4.5 kW | 5.5–11 kW | 7.5–15 kW |
Auxiliary fan power | 0.75 kW | 1.1 kW | 1.5 kW | 1.5 kW |
Vibrating sieve power (screen width) | 0.55 kW / 600 mm | 1.1 kW / 1000 mm | 1.1 kW / 1200 mm | 1.5 kW / 1500 mm |
Cooling system | Circulating water-cooled | Circulating water-cooled | Circulating water-cooled | Circulating water-cooled |
Grinding capacity (PVC) | 80–150 kg/h | 200–400 kg/h | 600–1000 kg/h | 800–1500 kg/h |
Overall dimensions (L×W×H) | 2200 × 1300 × 3000 mm | 3000 × 1800 × 3500 mm | 3200 × 1800 × 3700 mm | 3500 × 1800 × 3800 mm |
Advanced Dual Cooling System
Combined air and water cooling system effectively controls grinding temperature
Maintains grinding temperature below 45°C for PVC materials, preventing thermal decomposition
Maintains grinding temperature below 60°C for PE, PP and ABS materials, ensuring powder quality
High Precision Grinding System
Standard configuration of Cr12MoV alloy steel grinding discs, heat treated to HRC 58-62
Adjustable grinding gap from 0.1mm to 2mm, powder fineness adjustable from 20 to 120 mesh
Powder uniformity ≥90%, meeting most industrial application requirements
Fully Enclosed Dust-Free Design
Closed-loop pneumatic conveying system with cyclone separator and pulse dust collector
No dust leakage during operation, meeting international environmental protection standards
Powder recovery rate ≥99%, minimizing material loss
Simple & Low Maintenance
Quick-open grinding chamber, blade replacement and internal cleaning only take 20 minutes
Modular design, all wearing parts are standardized and easy to replace
Siemens motor with overload protection, stable operation for 24/7 continuous production
✅ 20+ years of experience in manufacturing solid waste recycling equipment
✅ CE and ISO certified products, exported to more than 80 countries
✅ Professional technical team provides customized solutions
✅ 12-month warranty period and lifelong after-sales service
✅ Fast delivery time: 15-30 days for standard models
✅ Overseas installation and commissioning service available
Contact us today to get the latest price and detailed technical information about our products. Our professional engineers will provide you with the most suitable recycling solution according to your needs.
