Alva Machinery Copper Wire Granulator is a professional high-efficiency recycling equipment specially designed for waste wires and cables. It adopts advanced two-stage crushing + air separation + electrostatic separation process, which can fully dissociate and separate copper granules and plastic insulation layers through pure physical methods without any chemical additives. Our cable granulators are widely used in scrap wire recycling stations, appliance dismantling plants and auto dismantling centers, with processing capacity ranging from 200kg/h to 1500kg/h.
Economic Benefit: Processing waste cables into clean copper granules increases their market value by 30-50%, and the separated plastic can also be sold as recycled raw materials, with a typical return on investment within 4-8 months.
99.9% Ultra-High Purity Separation
Three-stage separation process: crushing + air separation + electrostatic purification
Pure copper granule purity up to 99.9%, can be directly supplied to smelters
Plastic particle purity ≥99%, can be directly reused for extrusion and granulation
Comprehensive copper recovery rate ≥99.5%, minimal metal loss
Pure Physical & Zero Pollution Process
Full physical mechanical separation, no chemical reagents, no wastewater discharge
Fully enclosed negative pressure operation with pulse dust collection system
No dust and toxic gas leakage, fully meets international environmental standards
Low noise operation (<85dB), zero secondary pollution
Fully Automatic Continuous Production
PLC touch screen control system, one-button start for uninterrupted production
Automatic feeding, crushing, sorting and collection throughout the process
Only 1-2 operators required, greatly saving labor costs
Stable operation with low failure rate, supports 24/7 continuous work
Wide Material Compatibility
Suitable for all kinds of waste cables with diameter from 0.5mm to 50mm
Processes household wires, automotive wires, communication cables and electronic wires
Adjustable crushing particle size to adapt to different cable specifications
Special alloy cutter head with long service life and easy replacement
Model | Processing Capacity | Total Power | Copper Purity | Recovery Rate | Floor Space |
|---|---|---|---|---|---|
GM-S03 | 30-40 kg/h | 4.5 kW | 99%+ | 98.5%+ | 1.2×0.8×1.8m |
GM-S05 | 50-70 kg/h | 7.5 kW | 99%+ | 99%+ | 1.5×1.0×2.0m |
GM-S08 | 80-120 kg/h | 11 kW | 99%+ | 99%+ | 1.8×1.2×2.2m |
GM-S15 | 120-150 kg/h | 15 kW | 99%+ | 99.2%+ | 2.0×1.3×2.4m |
GMC-400 | 150-200 kg/h | 22 kW | 99%+ | 99.5%+ | 6×3×3.2m |
GMC-500 | 200-300 kg/h | 30 kW | 99%+ | 99.5%+ | 8×4×3.5m |
GMC-600 | 300-500 kg/h | 45 kW | 99%+ | 99.8%+ | 10×5×4.0m |
Note: Customized configurations are available for special cables such as thick armored cables and rubber cables.
Alva Machinery is a professional solid waste recycling equipment manufacturer with over 15 years of industry experience. We provide a complete range of high-quality recycling machines and turnkey solutions from crushing to sorting, all CE, ISO, TUV and SGS certified. With more than 500 successful projects in over 80 countries worldwide, we offer factory-direct prices, fast delivery, overseas on-site installation and 24/7 lifelong technical support to help you maximizeyour recycling profits.
