/ Product display /
![2]()
/ Product Usage /
The 800 PVC pulverizer is a versatile medium-to-large-scale powder processing machine suitable for large-scale grinding
of a variety of plastic and rubber materials, including PVC, PE, PS, ABS, EVA, PET, SBS, and SEBS. It is widely used in
industries such as chemicals, waste recycling, plastic modification, and wood-plastic composites. This machine
specializes in processing high-hardness and high-toughness materials, efficiently pulverizing PVC pipe/profile scrap,
expanded PE/EPS insulation boards, ABS electrical housings, and PPR pipe scraps. It is particularly adept at processing
thick-walled plastic parts and fiber-reinforced composites.
With a production capacity of 200-400 kg/h, the Model 600 meets diverse needs, from coarse powder filling to fine
modification. It can be widely used in scrap recycling lines of pipe and profile factories, decorative material
factories, and in the early stages of powder preparation for recycled plastic pellet manufacturers.
/ Crushing Range /
![未标题-1]()
/ Product advantages /
![12]()
01
Fine Grinding, High-Quality Powder:The machine's precision-engineered grinding components enable deep and uniform grinding of materials like PVC. The resulting powder boasts a fine and evenly distributed particle size, meeting stringent powder quality requirements in subsequent processes such as plastic modification and high-end product production, enhancing the performance and quality of the final product.
![13]()
02
Intelligent Control, Stable Operation: Equipped with an advanced intelligent control system, it precisely adjusts parameters such as feed rate and grinding pressure, automatically adapting to optimal operating conditions based on different material characteristics and grinding requirements. This ensures stable operation over extended periods, reduces failures caused by improper parameters, and ensures continuous production.
![14]()
03
Energy Saving and Consumption Reduction, Low Operating Costs: By optimizing the power system and mechanical transmission structure, the machine effectively reduces energy consumption while maintaining grinding efficiency. Compared to traditional grinding equipment, this system can save businesses significant amounts of electricity and other energy costs, significantly reducing production and operating costs over time.
![15]()
04
Easy Maintenance and Long Service Life:Key components are constructed from wear- and corrosion-resistant materials, and the overall modular design allows for easy assembly and disassembly of components, facilitating daily cleaning, maintenance, and upkeep. This effectively extends the equipment's service life and reduces production downtime due to equipment failure or component replacement.
/ Technical Parameter /
| Mode | Type 400 | Type 600 | Type 800 | Type 1000 |
| Cutter diameter | 400mm | 600mm | 800mm | 1000mm |
| Number of cutter discs | 18 piece | 28 piece | 36 piece | 42 piece |
| Motor power | 18 - 30KW | 45 - 55KW | 75 - 90KW | 90 - 110KW |
| Speed | 3900(r/min) | 3600(r/min) | 2800(r/min) | 2600(r/min) |
| Suction fan | 2.2 - 3KW | 4.5KW | 5.5 - 11KW | 7.5 - 15KW |
| Fan off | 0.75(KW) | 1.1(KW) | 1.5(KW) | 1.5(KW) |
| Vibrating screen | 0.55KW600 | 1.1KW1000 | 1.1KW1200 | 1.5KW1500 |
| Mill water | circulating water | circulating water | circulating water | circulating water |
| Grinding capacity | 80 - 150(Kg/h) | 200 - 400(Kg/h) | 600 - 1000(Kg/h) | 800 - 1500(Kg/h) |
| Installation dimensions | 220013003000(mm) | 300018003500(mm) | 320018003700(mm) | 350018003800(mm) |
